Please read the following safety precautions carefully before operating the machine. Since the machine generates a high-power laser, improper operation may result in fire, visual impairment, skin burns, inhalation of toxic substances, and other harmful or adverse health effects to people or property.
Please consult FLUX regarding any usage or safety concerns.
Email: support@flux3dp.com
Do not leave the HEXA operating unattended. Press pause if you need to step away.
Always have an accessible, functioning fire extinguisher in the workspace. | Do not stare at the light produced by the laser while the machine is cutting and engraving. |
Confirm the material to be engraved will be safe to burn at high temperatures. | Do not disassemble the machine without prior authorization from FLUX. |
Operators:
- Ensure that the personnel operating the machine have carefully read the safety instructions and follow the manual's guidelines.
- Minors should not be allowed to operate the machine unsupervised.
Safety Switch:
- When the cover is opened, the safety switch will interrupt the device's operation and stop the laser output. If the device does not stop operating when the cover is opened, turn off the power, cease operation, and contact customer service immediately.
- Even though the device is equipped with a safety switch, avoid placing your hands, eyes, or other body parts near the laser operation area to prevent accidents.
- When adjusting the optical path, ensure that you close the cover before testing to prevent burns caused by a failure of the safety switch.
- Do not operate the machine if the safety switch is malfunctioning. Do not attempt to disable the safety switch.
Work Environment:
- Place the device on a stable surface to prevent it from tipping over; it should not be overhanging or unstable.
- Set up the device indoors in well-ventilated areas with windows. Do not place the device outdoors, in basements, under metal roofs, or in other confined spaces.
- Connect the device's ventilation hose to the outside.
- In case of rain or extreme weather conditions, turn off the machine and bring the ventilation hose inside. Ensure the device is stored at a temperature between 5°C and 40°C and humidity between 10% and 75%. Maintain the working environment at 5°C to 25°C (the requirement is reduced to 5°C to 30°C if the performance is below 40%).
- Do not place liquids, flammable, or explosive items near the device.
- Children should not play or run around in the area where the device is located.
Ventilation:
- Connect the ventilation hose to the outside or an exhaust system to ensure the exhaust does not affect neighbors or public spaces.
- If you notice a strong odor or heavy smoke, stop using the device immediately. Ensure the ventilation hose is properly connected and the ventilation system is functioning correctly before resuming use.
Power and Cables:
- Verify whether the operating voltage of the ordered model is 110V or 220V.
- Ensure the third hole of the outlet is grounded. If grounding is not confirmed, static interference may affect performance and increase the risk of electric shock.
- If you find the power cable damaged, stop using the device immediately.
- Always turn off the device and unplug it when cleaning, maintaining, or disassembling internal parts with FLUX's approval.
- Do not allow cables and plugs to become damaged, lie near heaters, or be bent, twisted, pulled, or burdened with heavy objects.
Fire Hazard:
- Regularly clean the debris under the device's honeycomb table.
- If a flame appears on the engraving material during laser operation, immediately turn off the device, unplug it from the back, and extinguish the fire with a wet towel. Note that water can cause irreversible damage to the device.
- For larger flames, use a fire extinguisher. Be aware that dry powder or foam from the extinguisher can cause irreversible damage to the device.
- If the flame is uncontrollable, call the fire department immediately.
- Do not use materials unsuitable for laser processing—refer to "Material Tips - Hazardous Materials" for more information.
- Do not stack materials in the machine, such as attempting to cut multiple boards at once.
- Do not leave the machine running unattended.
Additional Operating Notes:
- Suggest that two or more people move the machine simultaneously to avoid injuries.
- Advise wearing gloves during cleaning to prevent scratches from the honeycomb table or materials.
- In case of burns, rinse with cold water and consult a doctor; do not self-medicate.
- Do not stare directly at the flame during laser operation.
- Strong vibrations can cause the optical path to shift or damage the laser tube.
EU Declaration of Conformity
The latest version of the Declaration of Conformity can be downloaded from: https://flux3dp.com/declaration/
